Single Mode OS2 MPO to MPO Fiber Patch Cable, 24 Fiber

The MPO/MTP trunk cables serve as a means of connecting cassettes, panels, or ruggedized MPO fan-outs in MDA, HAD, and EDA zones. They are well-suited for rapid deployment of high-density backbone cabling in data centers and other high-fiber environments, which minimizes network installation or reconfiguration time.

These trunk cables employ a compact and sturdy microcable structure and come in various colors, including SM, MM, and 10G MM. The fiber count ranges from 8,12,16,24,32 to 144, and the MTP/MPO polarity options include TIA Style A (up), Style B (down), and Style C (up/up). The cable length is customizable to meet specific requirements.

Single Mode OS2 MPO to MPO Fiber Patch Cable, 24 Fiber
ParametersValueParametersValue
Fiber Type9/125µm Singlemode OS2Fiber Count24-Fiber
Connector TypeMPO Female to MPO FemalePolishAPC to APC
Cable Length 1m,2m,3m … 500m or CustomizeCable Diameter3.0 mm
Insertion Loss≤0.7dBReturn Loss≥55dB
PolarityType B (Crossover)Durability≥200 times
Jacket MaterialLSZHJacket ColorYellow
EnvironmentOperating: -20°C to 70°C
Storage: -40°C to 85°C
ApplicationOptical switching interframe connections
High-density fiber card edge access
Array trunk cables
Data Center Cabling

This product comes with several features:
It supports 24-fiber MPO/MTP connectors as standard.
It is available in various types of optical fiber, including OS1/2, OM2, OM3, and OM4.
It supports different connector types, such as FC, LC, SC, ST, MU, and MTP.
The interface polished type options include PC, UPC, and APC.
It is available in a range of fiber counts, from 8,12,16,24,32 to 144.
The product undergoes 100% factory testing.
The discrete connectors use ceramic ferrules and sleeves that are heat-cured.
It allows for fan-out fibers from MPO/MTP connectors into individual simplex or duplex.
The product can be customized based on specific requirements such as length, staggering, connector type, breakout style, fiber count, and labeling fiber.
